Operation
Press the ON/RESET button on the back of each light to be used (option of using 2 - 5 lights). Hold for one second; the light will power on white. Note: the system is configured for five lights as a default.
Press the ON button on the controller. The lights will change from white to:
L1 - Red, L2 - Green, L3 - Blue, L4 - Purple, L5 – White
Note The lights are colored in order to determine which light number it is synced to.
Select the mode. You can choose either AT (automatic) or MT (manual). In AT mode, the lights will randomly activate basedupon the time selected. In MT mode, you manually select the lights by pressing the light number.a. Manual (MT) – In this mode the activated light is determined by the “Coach,” the participant needs to react to the lightwithin the selected time. If it is reacted to in time, no beep will sound. If not reacted to in time, the light willbeep. The “Coach” will continue to select (L1 – L5) light until the drill is over.b. Automatic (AT) Same as manual mode, except the light is randomly selected. The lights will continue to light up in arandom pattern until the end of the drill.
Select the time intervals (.5 to 7 seconds) by pressing corresponding number on controller
Select the color by pressing the “Color Bar” icon. You can select from Red, Green, Blue or White
For an added level of difficulty choose the “Color” button and each time a light is activated it will activate in a random color
Press OFF button to power off. Note: lights will automatically power off if there is no activity for 15 minutes. To reactivate, followsteps above.
Configuration – the system can be set up to use two to five lights
Select the which lights will be active by choosing the respective button (L1 – L5) on the remote.
If all five lights have been synced you can remove a light from the sync by pressing the light number (L1 – L5) on the controllerand holding down for 10 seconds – the red led on the controller will flash slowly at first and then speed up and turn off to indicatethe light is un-synced, the light will flash. The system should be in the off position
To add a light back into the configuration, you will need to identify which light (L1-L5) is not synced (red is for L1 light, the greenis for L2 light , the blue is for L3 , the purple is for L4 light, the white is for L5 light.) Example if when press ON Green, Blue & Purpleactivate, that means you can sync either L1 or L5.
Power the light on the press and hold the reset button on the back of the light until the light flashes, then press and hold the L1-L5 button that is not synced on the controller. The red led will flash slowly and increase in speed, when synced the light will beepand the red led will power off
The unit will remain in this configuration until reset.
Note: the system is configured for five lights as a default.
System Maintenance
When the battery is low, the buzzer will continuously sound. Shut down and recharge. System takes up to two hours to recharge and oncecharged will last up to 20 hours.
When charging, power off system. Red light indicates system is charging; green indicates fully charged.
